Gogova, Daniela and Tran, Dat and Stanishev, V. and Shafizadeh, Danial and Hsiao, Ching-Lien and Kim, Minho and Pécz, Béla and Kovács, András and Frey, Krisztina and Sulyok, Attila and Singh, Niraj Kumar and Febvrier, Arnaud Le and Eklund, Per and Darakchieva, Vanya (2026) Epitaxial MgSnN 2 on 4H‐SiC (0001): An Earth‐Abundant Nitride for Green Optoelectronics and Photovoltaics. ADVANCED OPTICAL MATERIALS, in pre. No. e71758. ISSN 2195-1071
|
Text
AdvancedOpticalMaterials-2026-Gogova-EpitaxialMgSnN2on4HSiC0001AnEarthAbundantNitrideforGreen.pdf - Published Version Available under License Creative Commons Attribution. Download (2MB) | Preview |
Abstract
Group II–IV‐Nitrides has emerged as a novel class of Earth‐abundant semiconductors. Owing to their tunable bandgaps these materials are attractive candidates for replacing expensive Ga‐based alloys in photovoltaics and green‐gap optoelectronics. In this work, epitaxial growth of MgSnN 2 thin films on 4H‐SiC (0001) substrates by direct current magnetron sputtering is demonstrated. Mg and Sn metal targets were co‐sputtered in a nitrogen‐containing atmosphere at growth temperatures up to 500 °C. The film composition is varied from Sn‐rich to stoichiometric and Mg‐rich regimes. X‐ray diffraction and cross‐sectional transmission electron microscopy confirm the MgSnN 2 layers grow epitaxially in a wurtzite crystal structure, exhibiting the epitaxial relationships with the substrate: MgSnN 2 [0001]//4H‐SiC [0001] and MgSnN 2 []//4H‐SiC[]. Improved crystalline quality is observed for higher deposition temperatures and stoichiometric composition, as evidenced by the narrowing of rocking curve's linewidths. Optical characterization reveals a high absorption coefficient (∼10 5 cm − 1 ) in the visible spectrum. Photoluminescence measurements show emission peaked at ∼2.4 eV, highly desirable for optoelectronic devices in the challenging green spectral region. These results establish MgSnN 2 as an earth‐abundant, environmentally‐friendly material, structurally compatible with III‐nitrides, with potential for cost‐efficient components in sustainable optoelectronics and photovoltaics.
| Item Type: | Article |
|---|---|
| Uncontrolled Keywords: | epitaxy , materials science , nitride , optoelectronics , photoluminescence , photovoltaics , semiconductor , sputter deposition , thin film , wurtzite crystal structure |
| Subjects: | T Technology / alkalmazott, műszaki tudományok > T2 Technology (General) / műszaki tudományok általában |
| SWORD Depositor: | MTMT SWORD |
| Depositing User: | MTMT SWORD |
| Date Deposited: | 15 Sep 2026 14:06 |
| Last Modified: | 15 Sep 2026 14:06 |
| URI: | https://real.mtak.hu/id/eprint/246395 |
